Indexable Inserts Type 3V
Indexable Inserts Type 3V
For making internal and external tools,threading tools and grooving tools
 |
 |
|
Type
|
Dimension(mm)
|
Approx unit weight(g)
|
||||||||
|
d
|
s
|
r
|
a≈
|
d
|
H
|
YG6
|
YG8
|
YT5
|
YT14
|
|
|
31005V
|
10.0
|
4.5
|
0.5
|
2.4
|
4.2
|
14.5
|
7.3
|
7.2
|
6.4
|
5.7
|
|
31310V
|
13.0
|
5.5
|
1.0
|
3.4
|
5.2
|
18.5
|
15.0
|
14.7
|
13.11
|
11.6
|
|
31320V
|
13.0
|
5.5
|
2.0
|
3.4
|
5.2
|
17.5
|
14.8
|
14.5
|
12.7
|
11.1
|
|
31605V
|
16.0
|
7.0
|
0.5
|
4.4
|
6.2
|
23.5
|
30.0
|
29.6
|
25.6
|
22.8
|
|
31620V
|
16.0
|
7.0
|
2.0
|
4.4
|
6.2
|
22.0
|
28.2
|
27.8
|
25.0
|
22.2
|
|
31910V
|
19.0
|
8.5
|
1.0
|
5.4
|
7.2
|
27.5
|
51.0
|
50.0
|
44.1
|
39.2
|
|
31920V
|
19.0
|
8.5
|
2.0
|
5.4
|
7.2
|
26.5
|
52.0
|
51.0
|
44.7
|
38.8
|
